镜头照明装置PMMA 德国赢创德固赛 TT70 高光级
- 品牌:德国赢创德固赛
- 货号:222
- 价格: ¥78/千克
- 发布日期: 2023-07-25
- 更新日期: 2025-12-05
产品详请
| 品牌 | 德国赢创德固赛 |
| 货号 | 222 |
| 用途 | 镜头照明装置 |
| 牌号 | TT70 |
| 型号 | TT70 |
| 品名 | PMMA |
| 外形尺寸 | 25 |
| 生产企业 | 德固赛 |
| 是否进口 | 是 |
ACRYMID® TT70
Polymethyl Methacrylimide Acrylic
Evonik Cyro LLC
产品说明:
ACRYMID® TT70 is a highly heat distortion-resistant poly(n-methyl methacrylimide) (PMMI).
Besides showing the properties common to all ACRYMID® molding compounds, such as
ACRYMID® TT70 has the following specific characteristics:
Application:
ACRYMID® molding compound is particularly suitable for injection molding of items meant for applications that involve maximum thermal loads.
Besides showing the properties common to all ACRYMID® molding compounds, such as
- excellent transmission and clarity,
- very high mechanical strength and rigidity,
- good weather resistance.
ACRYMID® TT70 has the following specific characteristics:
- high stability of the optical characteristics at long-lasting thermal load,
- highest heat deflection temperature under load.
Application:
ACRYMID® molding compound is particularly suitable for injection molding of items meant for applications that involve maximum thermal loads.
物性信息:
| 基本信息 | |
|---|---|
| 特性 |
|
| 用途 |
|
| 形式 |
|
| 加工方法 |
|
| 物理性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 密度 | 1.21 | g/cm3 | ISO 1183 |
| 溶化体积流率(MVR) (260°C/10.0 kg) | 1.70 | cm3/10min | ISO 1133 |
| 吸水率 (平衡, 23°C, 50% RH) | 6.0 | % | ISO 62 |
| 机械性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 拉伸模量 | 4000 | MPa | ISO 527-2/1 |
| 拉伸应力 (断裂) | 80.0 | MPa | ISO 527-2/5 |
| 拉伸应变 (断裂) | 3.0 | % | ISO 527-2/5 |
| 冲击性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 简支梁无缺口冲击强度 (23°C) | 20 | kJ/m2 | ISO 179/1eU |
| 热性能 | 额定值 | 单位制 | 测试方法 |
|---|---|---|---|
| 热变形温度 | |||
| 0.45 MPa, 未退火 | 158 | °C | ISO 75-2/B |
| 1.8 MPa, 未退火 | 149 | °C | ISO 75-2/A |
| 维卡软化温度 | 170 | °C | ISO 306/B50 |
