PP 美国塞拉尼斯 GF30-04 增强级
- 品牌:美国塞拉尼斯
- 货号:555
- 价格: ¥10/千克
- 发布日期: 2023-11-29
- 更新日期: 2024-10-23
产品详请
品牌 | 美国塞拉尼斯 |
货号 | 555 |
用途 | |
特性级别 | 增强级|||耐老化|||抗化学性|||高光泽||| |
牌号 | GF30-04 |
型号 | GF30-04 |
加工级别 | 注塑级|||滚塑级||| |
品名 | PP |
外形尺寸 | 25 |
用途级别 | 通用级|||电子电器部件|||型材|||薄壁制品||| |
生产企业 | 美国塞拉尼斯 |
是否进口 | 是 |
Celstran® PP-GF30-04 Natural
Polypropylene
Celanese Corporation
30% 长玻璃纤维
产品说明:
Polypropylene homopolymer reinforced with 30 weight percent long glass fibers. The fibers are chemically coupled to the polypropylene matrix. The pellets are cylindrical and normally as well as the embedded fibers 10 mm long. (-0403 = heat stabilized, -0405 = UV stabilized, -0453/-0455 = low emission)
Parts molded of CELSTRAN have outstanding mechanical properties such as high strength and stiffness combined with high heat deflection. The notched impact strength is increased at elevated and low temperatures due to the fiber skeleton built in the parts. The long fiber reinforcement reduces creep significantly.
The very isotropic shrinkage in the molded parts minimizes the warpage.
Complex parts can be manufactured with high reproducibility by injection molding.
Application field: Functionial/structural parts for automotive
Parts molded of CELSTRAN have outstanding mechanical properties such as high strength and stiffness combined with high heat deflection. The notched impact strength is increased at elevated and low temperatures due to the fiber skeleton built in the parts. The long fiber reinforcement reduces creep significantly.
The very isotropic shrinkage in the molded parts minimizes the warpage.
Complex parts can be manufactured with high reproducibility by injection molding.
Application field: Functionial/structural parts for automotive
物性信息:
基本信息 | |
---|---|
填料/增强材料 |
|
特性 |
|
用途 |
|
外观 |
|
形式 |
|
加工方法 |
|
树脂ID (ISO 1043) |
|
物理性能 | 额定值 | 单位制 | 测试方法 |
---|---|---|---|
密度 | 1.12 | g/cm3 | ISO 1183 |
机械性能 | 额定值 | 单位制 | 测试方法 |
---|---|---|---|
拉伸模量 | 7000 | MPa | ISO 527-2/1A/1 |
拉伸应力 (断裂) | 130 | MPa | ISO 527-2/1A/5 |
拉伸应变 (断裂) | 2.7 | % | ISO 527-2/1A/5 |
弯曲模量 (23°C) | 6600 | MPa | ISO 178 |
弯曲应力 (23°C) | 200 | MPa | ISO 178 |
